Immersion Gold 2u'' FR4 PCB board 2.0mm Board thickness0.1mm Trace Width

Item Mass Production Pilot Run Production
Capacity Capacity
Layer Counts 1L—18L,
Material CME1,CME3,FR-4, High TG FR4 , Halogen-free FR4 , aluminium ,Ceramic(96% Alumina)
Teflon,PTFE(F4B,F4BK), Rogers(4003,4350,5880)Taconic(TLX-8,TLX-9), Arlon(35N,85N)etc.
Material Mixed Laminate 4 layers -- 10 layers 12 layers
FR4+Ro4350 , FR4+Aluminium , FR4+ FPC
Maximum Size 610mm X 1200mm 1200 - 2000MM
Board Outline Tolerance ±0.15mm ±0.10mm
Board Thickness 0.125mm--6.00mm 0.1mm--8.00mm
Thickness Tolerance ( t≥0.8mm) ± 8% ±5%
Thickness Tolerance( t<0.8mm) ±10% ±8%
Minimum Line / Space 0.10mm 0.075mm
Trace width Tolerance 15%-20% 10%
Minimum Drilling Hole (Mechanical) 0.2mm 0.15mm
Minimum laser hole 0.1mm 0.075mm
Hole Position/hole Tolerance ±0.05mm PTH:±0.076MM NPTH:±0.05mm
Mini hole ring (single 0.075MM 0.05MM
OutLayer Copper Thickness 17um--175um 175um--210um
InnerLayer Copper Thickness 17um--175um 175um--210um
Mini Solder Mask Bridge 0.05mm 0.025mm
Impedance Control Tolerance ±10% ±5%
Surface Finishing HASL, Lead free HASL, Immersion gold, Immersion tin, Immersion Silver.
Plated gold , OSP, Carbon ink,
1-2L Lead-time 3-7 days 1-2 days
4- 8L Lead-time 7-10 days 2-7 days
10-18L Lead-time 10-15 days 4-9 days
20-28L Lead-time 15-20 days
Acceptable File Format ALL Gerber Files,POWERPCB,PROTEL,PADS2000,CAD,AUTOCAD,ORCAD,P-CAD,CAM-350,CAM2000 etc.
Quality Standards IPC-A-600F and MIL-STD-105D CHINA GB<4588>

Global Success Circuits Co., Ltd.  (www.szgpc.com)  was established in Shenzhen China on May 2005, which is a world’s leading PCB manufacturer focused on high-precision double sided and multilayer PCB, Aluminium PCB, HDI and Rigid-Flex PCB, and SMT assembly one service. After more than 10 years developing, Global Success based on accurate market positioning, customer-centric service concept and excellent corporate culture, it has become a group company with a number of subsidiaries in Shenzhen, Jiangxi, Jiangsu and employ more than 1000 people.

     Global Success owns mature PCB manufacturing technology, state-of-the-art process technique and production process control technology of the industrial, as well as the professional R&D team. Furthermore, Global Success has gradually got ISO9001 Quality Management System Authentification, UL, CQC, ISO14001 Environment Management System Authentification, ISO/TS16949 Car Quality Management System Authentification and OHSA18001 Occupation Health and Safety Management System certificate. As a leading global PCB manufacturer, Global Success has consistently adhered to the customer-centric, market-oriented core value over the years. Sincerely cooperate, abide by its commitment,to provide high quality service to customers around the world with all efforts,strive to realize Win-Win with customers and cooperative partner. At the same time,as a corporate citizen, we actively carry out all kinds of social responsibility, devote to become the practitioners of era responsibility and the social civilization spreader.

We hope to establish the strategic partnership with customers, constantly strive to the corporate vision of  “to become a one-stop PCB and PCBA service experts”!
