    TG150 Automotive Copper Clad Printed Circuit Board 2Oz Copper PCB 0.1mm Width

    TG150 Automotive Copper Clad Printed Circuit Board 2Oz Copper PCB 0.1mm Width


    Layer Printed Circuit Board
    FR4 Material 1.60MM
    2oz Finish Copper Thickness
    Surface Finish: Immersion Gold
    Min Line/Space: 5/5mil
    Hole Size: 0.35mm
    Used for Industrial Control
    Produced by China PCB Facbrication


    Industrial control system (ICS) is a general term that encompasses several types of control systems used in industrial production,including supervisory control and data acquisition (SCADA) systems, distributed control systems (DCS), Programmable Automation,Controllers, PLCs, Data Communications,Signal Conditioners, Signal Converters, Embedded Controllers, Industrial Ethernet.

    Switches and other smaller control system configurations such as skid-mounted programmable logic controllers (PLC) often found in the industrial sectors and critical infrastructures.
    ICSs are typically used in industries such as electrical, water, oil, gas and data
    CategoryDescriptionCapability
    Laminate MaterialFR4, High TG FR4(tg150,tg170,tg180)
    Halogen-free FR4, CEM1, CEM3,Polyimide,
    Rogers ,Aluminum
    We will order other special material accoprding to your request
    Board LayersMaximum layers1-18layers
    SizeMaximum finished dimensions500*1200mm
    Board ThicknessMinimum and Maximum0.2-3.2mm
    CopperOuter copper weight0.5oz (17um) - 4oz (140um)
    Inner copper weight0.5oz (17um) - 4 oz (105um)
    DrillingMinimum drilling size0.15mm
    Drill Deviation (True position size)2mil (0.050mm)
    PTH hole tolerance3mil (0.075mm)
    N-PTH hole tolerance2mil (0.050mm)
    Minimum hole wall thickness20um
    Angle of Countersink80°, 90°, 100°, 120°
    Circuit lineMinimum width0.1mm/ 4mil
    Minimum space0.1mm/ 4mil
    Inner LayersMinimum space from drilling to inner pattern6mil (0.15mm)
    Minimum space from annular ring to inner pattern6mil (0.15mm)
    Layer-to-layer registration3mil (0.08mm)
    Board ProfillingHole to board edge tolerance±4mil (0.1mm)
    Pattern to board edge tolerance±4mil (0.1mm)
    CNC Tolerance±4mil (0.1mm)
    Minmum thickness after V-Cut12mil (0.3mm)
    V-Cut tolerance±5mil (0.12mm)
    V-Cut Angle20,30,45,60
    Solder maskColorgreen, light green, matte green, white black,matte black,yellow,red, blue
    Thickness≥17um
    SilkscreenColorWhite, black, yellow,
    red, blue, green, gray
    Minimum line height≥0.0625mm
    Minimum line width≥0.125mm
    Surface FinishHASL, HASL pb free, immersion gold, immersion silver, O.S.P
    CertificationIPC-A-600 Class II/III, UL E324220, ISO 9001,ISO/TS16949, ROHS
